Testing Procedures
©2005 Maytag Services 15 16026268
WARNING
!
Disconnect power before performing the following
procedures unless testing requires power.
Control Key Panel
1. Disconnect power to oven and remove outer case,
(see “Outer Case” section in Disassembly
Procedure).
2. Remove control panel, (see “Control Panel” section in
Disassembly Procedure).
3. Discharge high voltage capacitor, (see "High Voltage
Capacitor" section in Disassembly Procedure).
4. Disconnect ribbon connector by sliding top part of
connector upward. Once in released position remove
ribbon from connector by sliding ribbon side-to-side.
NOTE: Caution should be used when removing cable
from connector. Ribbon cable has two holes
which connector locks the ribbon in place.
Key pad matrix for ACM0720A*, UMC1061A*,
UMC5200A*
Pad Conn. Pad Conn.
1 ...................... 1 - 8 Stop/Clear ................. 4 - 8
2 ...................... 1 - 9 Auto Defrost.............. 4 - 9
3 ...................... 1 - 10 Clock ........................ 4 - 10
4 ...................... 1 - 11 Popcorn .................... 5 - 8
5 ...................... 2 - 8 Potato ....................... 5 - 9
6 ...................... 2 - 9 Beverage .................. 5 - 10
7 ...................... 2 - 10 Dinner Plate .............. 5 - 11
8 ...................... 2 - 11 Fresh Vegetable........ 6 - 8
9 ...................... 3 - 8 Frozen Entree ........... 6 - 9
0 ...................... 3 - 9 Start .......................... 6 - 10
Program .......... 3 - 10 Timer ........................ 7 - 9
Power Level ..... 3 - 11 Easy Cook ................ 7 - 10
Key pad matrix for ACM1120A* and ACM1420A*
Pad Conn. Pad Conn.
Clock .................. 1 - 8 Beverage ............... 5 - 8
Control Set-up .... 1 - 9 Potato .................... 5 - 9
More ................... 1 - 10 Popcorn ................. 5 - 10
Less.................... 1 - 11 Pizza ...................... 5 - 11
6 ......................... 2 - 8 Timer ..................... 5 - 12
7 ......................... 2 - 9 Auto Defrost .......... 6 - 8
8 ......................... 2 - 10 Program ................ 6 - 9
9 ......................... 2 - 11 Power Level ........... 6 - 10
0 ......................... 2 - 12 Rapid Defrost ........ 6 - 12
Stop/Clear .......... 3 - 8 1 ............................ 7 - 8
Fresh Vegetable . 3 - 9 2 ............................ 7 - 9
Easy Cook .......... 3 - 12 3 ............................ 7 - 10
Frozen Entree ..... 4 - 10 4 ............................ 7 - 11
Start .................... 4 - 11 5 ............................ 7 - 12
Key pad matrix for ACM0860A*, ACM1460A*,
ACM2160A*, and MMC5086A*
Pad Conn. Pad Conn.
Sensor Popcorn .. 1 - 8 Start ....................... 4 - 10
Easy Cook .......... 1 - 9 4 ............................ 4 - 11
Power level ......... 1 - 10 Control Set-up ....... 5 - 8
1 ......................... 1 - 11 8 ............................ 5 - 10
Warm Hold .......... 2 - 8 5 ............................ 5 - 11
Program .............. 2 - 10 Timer...................... 6 - 8
2 ......................... 2 - 11 More ...................... 6 - 9
Rapid Defrost ..... 2 - 12 9 ............................ 6 - 10
Sensor Cook....... 3 - 8 6 ............................ 6 - 11
Sensor Reheat ... 3 - 9 Clock ..................... 7 - 8
Stop /Clear ......... 3 - 10 Less ....................... 7 - 9
3 ......................... 3 - 11 0 ............................ 7 - 10
Auto Defrost ....... 4 - 8 7 ............................ 7 - 11
Auto Cook........... 4 - 9
