Maytag AFU2005BW - Wiring Diagram and Schematic; Manual Defrost Models

To avoid risk of electrical shock, personal injury, or death, disconnect power to freezer before servicing, unless
testing requires it. Wires removed during disassembly must be replaced on proper terminals to insure correct
grounding and polarization.
CAUTION
!
High Voltage
!
WARNING
Wiring Diagram and Schematic
50 16023585 ©2004 Maytag Services
Control
Black
Black Black White
Red
Overload
protector
Compressor
Interior
light
Light
switch
Ground schematic
To 115 VAC plug
Ground
White
1 - Outer case
2 - Compressor
3 - Control
4 - Light plate
C
PTC
relay
R
S
Capacitor
Control
Black
Black
Black
Black
White
White
Compressor
Red
Ground
Red
Green
Light Switch
Light Plate (ground)
Light
No Interior Light (Optional)
Red
Green
Black
Service Cord
Capacitor
Manual Defrost Models
AFU1202BW AFU1705BW
AFU1505BW AFU2005BW
AQU1525AEW MQU2056ARW
MQU1554AEW MQU2057AEW
MQU1556AEW
