6
Tools Needed:
203 mm (8") 203 mm (8") or 254 mm (10") Flat-blade screwdriver Phillips screwdriver
or 254 mm (10") Adjustable wrench
Pipe wrench that opens to 25 mm (1")
Torx T20
®†
Security 25 mm (1") Hex-head 8 mm (5/16") Socket wrench Pliers
screwdriver or bit socket wrench (that open to 39 mm [1
9
/
16
"])
Level Utility knife 6 mm (1/4") Nut driver Locking pliers
Caulk gun and caulk Vent clamps Pipe-joint compound 686 mm (27") Wood block
(for installing new exhaust vent) suitable for gas type
Flashlight (optional) 25 mm (1") Ruler or measuring tape Putty knife
Open-end wrenches
TOOLS & PARTS
†® TORX and T20 are registered trademarks of Acument Intellectual Properties, LLC.
NOTE: The circuit diagram for this dryer is located inside the lower front panel, within the Tech Sheets.
NOISE: Sound Pressure Level, Lpa: 58 dBA (uncertainty,
Kpa: +/–10 dBA).
Technical Specications:
220–240 V, 50 HZ. 10A
Total mass: 68 kg max.
Parts Supplied:
n Foot boots (4)
n Leveling legs (4)
n PN models: Card reader bezel, hardware
