Connecting the Water Supply
To reduce the risk of injury or death, follow
basic precautions, including the following:
• Read all instructions before installing ice maker.
•
Do not attempt installation if instructions are not
understood or if they are beyond personal skill
level.
• Observe all local codes and ordinances.
•
Do not service ice maker unless specifically
recommended in Use & Care Guide or published
user-repair instructions.
• Disconnect power to refrigerator
before installing
ice maker.
• Water damage due to an improper water
connection may cause mold/mildew growth. Clean
up spills or leakage immediately!
WARNING
7
Installation
Notes
• There is a slight curve to
the freezer handle.
• For proper installation, be
sure handle is oriented as
shown.
To Install:
1. Align door handle clips to the studs attached to the
freezer drawer.
2. Ensure the large hole in the mounting clip is
positioned to the
right on both ends of handle.
3. Rotate the handle so that the handle is flat against
the door.
Freezer Handle
To Remove:
1. With both hands, firmly grasp the handle toward
the right side.
2. Slide toward the
left, lift and remove from the
surface.
4. Grasp the handle firmly and slide handle to the
right.
To Remove:
• Loosen set screws in handle using
3
⁄32” Allen
wrench.
• Repeat the procedure on all screws.
To Replace:
• Align handle with the mounting posts.
• Apply upward pressure to the handle and hold.
• Fully tighten all set screws to secure handle in
place.
Metal Handle
Materials Needed:
•
3
⁄32” Allen wrench
• Gloves to protect hands
Note: Metal handles can scratch doors.
Handle
Clip
Handle
Base
Door Stud
To Next Page
