52 PROGRAMMING MANUAL 516532 B PUBLICATION DATE 1 JUN 2007.DOC
DIAGNOSE:
1. Check if the Gen 2 Debit Card Reader is
connected to the wash computer
Connect the Gen 2 Debit Card Reader to the wash
computer
2. Check that the wash computer is setup to
work with a Gen 2 Debit Card Reader
Adjust the wash computer settings so that Enhanced
Debit is selected at the Pricing menu.
3. Check if the wiring is still continue Repair the wiring
DIAGNOSTIC CODE D17 : BIMETAL/SPRING
The bimetal/Spring is an extra security that the door can not be opened immediately when the power is
switched off. To verify that the bimetal/Spring is not defective, the bimetal/Spring is checked each cycle. If the
bimetal/Spring is defective : at the end of the program, Diagnostic Code D17 is displayed.
DIAGNOSE(ERR10):
1. Check the bimetal/Spring If the bimetal/Spring is defective: replace the
bimetal/Spring
2. Check the mechanical functionality of the
door lock.
If the door lock is not functioning mechanically:
replace the door lock system
3. Check the continuity of the wiring If the wiring is not continuous: repair the wiring
DIAGNOSTIC CODE D18 : MEMORY ERRORS
If a memory error occurs then something is going wrong with the EPROM.
Try to reload the Programs. Check for source of electrical „noise“.
DIAGNOSTIC CODE D19 : SOFTWARE ERRORS
Software errors must never occur. If a software error message occurs inform the manufacturer.
HELP CODE H50 : TOO HOT
When the water temperature is 27°F above the target temperature : Help Code 50 will be displayed.
For evaluation of the problem, you can follow the water temperature of the bath on the display of the washing
machine at the STATUS-menu. (Select Cycle-Status Menu at Main Menu).
DIAGNOSE(ERR15):
1. Check if the correct water inlet valves are
Functional.
If the cold water inlet valves are not
Functional or if the main cold water supply
is not available and only hot water inlet
valves are open, and if the hot water supply
has a temperature value above the
programmed wash sequence value then the
temperature of the wash bath will be too
high.
See diagnostics Failure 11 : Fill Failure
2. Check the water temperature If the temperature of the supplied hot water is too high:
decrease the temperature of the hot water
3. Check if the temperature sensor is
functioning
If the temperature sensor is defective:
replace the temperature sensor
4. Check the output relay that powers
the hot water inlet valves
If the relay stays closed and the relay is broken,
replace the wash computer
