CHASSIS PARTS
6
For Model: MGR6875ADB26
(Black)
W10274623
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 3826W047−45 Extension, Lower
Vent
2
8004P024−60 Spacer, Side Panel
3
7101P618−60 Screw, Shoulder
4
2618F194−70 Panel, Side
5
3801F656−51 Bracket, Anti−Tip
6
3823F015−51 Spacer, Side Panel
(Long)
7
3801F924−80 Bracket, Cooktop
8
7101P507−60 Foot, Leveler (4)
9
W10206589 Fan, Convection
10 Sensor, Oven
7430P045−60 Upper Oven
7430P041−60 Lower Oven
11
7450P108−60 Switch, Light Assy
12
7101P388−60 Screw
13
4005F743−51 Cover, Bottom Wire
14
W10210727 Cover, Upper Wire
15 Bracket
3801F705−51 Right
3801F706−51 Left
16
W10180198 Back, Main
17
3807F647−45 Plate, Broil
Fitting
18
7101P633−60 Screw (2)
19 Support, Upr Oven
3807F643−45 Right
3807F644−45 Left
20
3804F212−45 Retainer,
Insulation
21
7101P385−60 Screw
22
W10283986 Cover, Bottom
Insulation
23
W10260703 Support, Lwr Oven
24
7407P179−60 Light Assy. (2)
25
899138−001 Bulb, Light (2)
26
8002P077−60 Latch, Door Lock
27 Bottom, Burner Box
W10283688 Right
W10283722 Left
28
3601F321−50 Baffle, Vent Seal
29
3826W042−45 Extension, Upper
Vent
30
4022W055−45 Flue Assy., Upper
31
3826W052−45 Flue Assy., Lower
32
7101P375−60 Screw
33
7212P066−60 Seal, Front Frame
34
4005F736−45 Cover, Burner
Opening (2)
35
3601F308−19 Baffle, Lower Oven
Vent
36
2205F055−19 Bottom, Upper Oven
37
2205F051−19 Bottom, Lower Oven
38
3608F088−70 Trim, Kickplate
39
3804F212−45 Retainer, Bottom
Insulation
40 Pan, Bake
3401F091−45 Lower
3401F090−45 Upper
41
3605F338−19 Plate, Fan Cover
42
7101P385−60 Screw
43
4005F741−51 Cover,
Covect Motor
44
7101P376−60 Screw
INSULATION
Insulation, Wrap
7002P310−60 Upper Oven
7002P413−60 Lower Oven
Insulation, Back
7002P415−60 Upper Oven
7002P419−60 Lower Oven
