COMPONENTS TEST PROCEDURES RESULTS
HIGH-VOLTAGE
CAPACITOR
HIGH-VOLTAGE
DIODE
HEATER ELEMENT
1. Remove wire leads.
2. Measure resistance. (ohm meter scale:
Rx1000)
(1) Terminal to terminal
Ohm-meter
(2) Terminal to case
Ohm-meter
1. Measure continuity. Forward.
(ohm meter scale: Rx1000)
Ohm-meter
1. Measure continuity. Reverse.
(ohm meter scale: Rx1000)
Ohm-meter
1. Remove wire leads.
2. Measure resistance.
(ohm meter
scale:Rx1)
Normal:
Momentarily indicates several ohm, and
then gradually returns to infinite
Normal: Infinite.
Normal:Continuity.
Abnormal: Infinite.
Normal: Infinite.
Abnormal: Continuity.
Normal: Approximately
Abnormal: Infinite or several.
Figure 25-a
Figure 25-b
Figure 26-a
Figure 26-b
Conv. HTR
15-25
Grill HTR
25-30
