3-23
Knowing Your Mazda
Doors and Locks
Form No. 8Q36-EA-01F
3. Tighten the bolt at both ends of the rear
cross bar alternately and evenly.
4. Install the rear cross bar cover by
inserting the clips into the square hole
of the rear cross bar until they click,
then tighten the screw.
NOTE
•
If only one bolt is tightened, the
cross bar will lean to one side.
•
Tighten the bolts with tightening
torque of 11—12 N•m {110—120
kgf•cm}.
Bolt
Screw
Rear cross bar
cover
Rear cross bar
