DESCRIPTION FUSE RATING PROTECTED COMPONENT
18 AUDIO 30A
Audio system
(BOSE Sound System-equipped model)
19 ABS IG 10A ABS
í
, DSC
í
20 FOG 15A Front fog lights
í
21 HORN 15A Horn
22 DRL 10A DRL
í
23 H/CLEAN ――
24 F/PUMP 15A Fuel pump
25 P/ST IG 10A Power steering
26 A/C MAG 10A Air conditioner
í
27 ALT/TCM 10A/15A TCM
í
28 GLOW SIG ――
29 P.OUTLET ― Power outlet
30 ENG +B 10A PCM
31 ROOM 15A Interior lights
32 ENG BAR 4 10A O
2
sensors
í
33 ENG BAR 3 10A O
2
sensors
34 EGI INJ 10A Injector
35 ENG BAR 1 10A For protection of various circuits
36 ENG BAR 2 10A PCM, Fuel pump
8-56
Maintenance and Care
í
Some models.
