DASHBOARD
ILLUMINATION/
DIMMER
1
/TRIP METER
2
1
•Rotatetheknobtoadjustthebrightnessoftheinstrumentclusterandotherdashboardilluminations.
2
•Pushtotogglebetweentripmeter(A&B).
 •
Whenatripmeterisselected,pushandholdtoresettozero.
TPMS NOTE:Lowambienttemperatureand/orhighaltitudecausestirepressuresto
dropandmayturntheTPMSwarninglighton.Ifthewarninglightcomeson,checkthetire
pressureandllthetiresassoonaspossible,preferablybeforemovingthevehicleand
warmingupthetires.Tirepressureshouldbecheckedwhenthetiresarecold.
Brake Warning Light
Parkingbrakeon/lowbrake
uid/malfunction
AFS
OFF
Adaptive Front Lighting
System (AFS) OFF (p.19)
Charging System
Malfunction
Door/Liftgate Ajar
Low Washer Fluid Level
Warning Light
ABS (Antilock Brake
System) Malfunction
Low Fuel Level
Check Fuel Cap (p.17)
 Perform
Maintenance
FUEL
GAUGE
ODOMETER/
TRIP METER
ENGINE COOLANT TEMP LIGHTS
Sincethisvehicledoesnotuseanenginecoolant
temperaturegauge,redandblueenginecoolant
temperaturelightsareusedtoindicatehighandlow
coolanttemperature.
Red Coolant Temp Light
Flashing:Engineisstartingtorunhot.
Driveslowlytoreduceengineload.
On:Engineisoverheating.Safelypulloverto
thesideoftheroadandturntheengineoff.
RefertotheOwner’sManualformoreinformation.
Blue Coolant Temp Light
On:Enginecoolantiscoldandnowarm
airisavailableforheater/defroster.
 Off:Enginecoolantiswarmandwarmairis
 availableforheater/defroster.
 Thelightmaystayonforafewminutesafter
 start-upwhentheengineiscold,butthe
 vehiclecanbedrivenwiththelightonoroff.
INFORMATION
DISPL AY
AMBIENT
TEMPERATURE
Seepage8orthe
Owner’sManualfor
furtherinformation.
