Mazda 3 2016 - Instrument Cluster and Display; Meters and Gauges

4 – 11
When Driving
Instrument Cluster and Display
Meters and Gauges
Type A
Type B
Type C
Steering Switch
(Digital Speedometer Type)
(Analog Speedometer Type (With Tachometer))
(Analog Speedometer Type (Without Tachometer))
Some models.
Instrument Cluster

Speedometer .......................................................................................................... page 4-12

Odometer, Trip Meter and Trip Meter Selector .................................................... page 4-12

Tachometer ............................................................................................................ page 4-14

Fuel Gauge ............................................................................................................ page 4-14

Dashboard Illumination......................................................................................... page 4-15

Outside Temperature Display ................................................................................ page 4-16

Cruise Control Set Vehicle Speed Display ............................................................ page 4-16

Active Driving Display ......................................................................................... page 4-18
