Mazda 3 2016 - Page 466

6 – 62
Maintenance and Care
Owner Maintenance
Trunk light (4–Door)
1. Press both sides of the lens cap to
remove it.
2. Disconnect the bulb by pulling it out.
3. Install the new bulb in the reverse order
of the removal procedure.
Luggage compartment light (5–Door)
1. Wrap a small À athead screwdriver with
a soft cloth to prevent damage to the
lens and remove the lens by carefully
prying on the edge of the lens with the
À athead screwdriver.
2. Disconnect the connector from the unit
by pressing the tab on the connector
with your ¿ nger and pulling the
connector.
3. Disconnect the bulb by pulling it out.
4. Install the new bulb in the reverse order
of the removal procedure.
