6 – 66
Maintenance and Care
Owner Maintenance
*Some models.
DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
19 CNG 15 A —
20 AT 15 A Transaxle control system
21 R.WIPER 15 A Rear window wiper
*
22 A/C 7.5 A Air conditioner
23 ENGINE3 15 A Engine control system
24 ENGINE2 15 A Engine control system
25 ENGINE1 15 A Engine control system
26 GLOW SIG 5 A —
27 EVVT 20 A Engine control system
28 WIPER 20 A Front window wiper and washer
29 DCDC REG 30 A —
30 FUEL PUMP2 30 A —
31 ADD FAN DE 40 A —
32 P.WINDOW1 30 A Power windows
33 H/L LOW R 15 A Headlight low beam (RH)
*2
34
H/L LOW L
HID L
15 A Headlight (LH)
*1
, Headlight low beam (LH)
*2
35 METER1 10 A Instrument cluster
36 IG2 30 A For protection of various circuits
37 LPG 30 A —
38 FAN DE 40 A —
39 DCDC DE 40 A —
40 SRS1 7.5 A Air bag
41 ENGINE. IG1 15 A Engine control system
42 C/U IG1 15 A For protection of various circuits
43 — — —
*1 With xenon fusion headlights
*2 With halogen headlights
