Instrument Cluster and
Display
▼
Instrument Cluster and Display
① Instrument Cluster................. page 4-12
② Active Driving Display..........page 4-28
Instrument Cluster
▼
Instrument Cluster
① Tachometer.............................page 4-13
② Multi-information Display.....page 4-14
③ Engine Coolant Temperature
Gauge.....................................page 4-17
④ Fuel Gauge.............................page 4-17
⑤ Dashboard Illumination Switch.............
............................................... page 4-18
⑥ Speedometer.......................... page 4-12
⑦ TRIP Switch...........................page 4-16
▼
Speedometer
The speedometer indicates the speed of the
vehicle.
When Driving
Instrument Cluster and Display
4-12
