Refer to Mazda Radar Cruise Control
(MRCC) on page 4-118.
Refer to Mazda Radar Cruise Control
with Stop & Go function (MRCC with
Stop & Go function) on page 4-127.
Refer to Cruising & Traffic Support
(CTS) on page 4-139.
Refer to Lane-keep Assist System
(LAS) on page 4-152.
Refer to Smart Brake Support (SBS) on
page 4-155.
Refer to Smart Brake Support [Rear]
(SBS-R) on page 4-159.
Refer to Smart Brake Support [Rear
Crossing] (SBS-RC) on page 4-163.
Refer to Cruise Control on page 4-211.
▼
Compass Display
The direction the vehicle is moving is
displayed in one of eight directions while
the vehicle is being driven.
Display Direction
NNorth
S South
EEast
WWest
NE Northeast
NW Northwest
SE Southeast
SW Southwest
▼
Warning (Display Indication)
A message is displayed to notify the user
of the system operation status and
malfunctions or abnormalities.
If the warning light turns on/flashes
simultaneously or a symbol is indicated in
the display, check the information
regarding the warning light or symbol.
Refer to If a Warning Light Turns On or
Flashes on page 7-26.
For messages not indicating a symbol,
follow the instructions indicated in the
multi-information display.
Refer to Message Indicated on
Multi-information Display on page 7-38.
▼
Warning/Indicator Lights
Instrument Cluster varies depending on
model and specifications.
1. Instrument Cluster
2. Front Center of Headliner
Warning lights will appear in any of the
highlighted areas
When Driving
Instrument Cluster and Display
4-21
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10
