DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
15 EHPAS 80 A EHPAS
í
16 FOG 15 A Front fog lights
í
17 D.LOCK 20 A Power door lock
18
P.WIND
H/CLEAN
20 A Headlight washer
í
, Power windows
í
19 MAG 10 A Magnet clutch
20 DEFOG 25 A Rear window defroster
21 ENG+B 10 A PCM
22 STOP 10 A Brake lights
23 FUEL 20 A Fuel pump
í
, Fuel warmer
í
24 HAZARD 10 A Turn signals, Hazard warning flashers
25 ROOM 15 A
Overhead lights, Map lights, Luggage compartment light, For
protection of various circuits
26 ―― ―
27 ―― ―
28 GLOW SIG 7.5 A PCM
í
29 HEAD HR 10 A Headlight high beams (RH)
30 HEAD HL 10 A Headlight high beams (LH)
31 HORN 15 A Horn
32 SUN ROOF 20 A Sunroof
í
33
ETC MIRROR
BURGLAR
7.5 A Theft-Deterrent System
í
34 HEAD LR 15 A Headlight low beams (RH), Manual Headlight leveling
í
35 HEAD LL 15 A Headlight low beams (LH)
36 ENG BAR2 15 A O
2
heater
í
37 ENG BAR 15 A Air flow sensor, Engine control system
38 INJ 20 A Injector
í
, PCM
í
39 ILLUMI 10 A Illumination
40 TAIL 10 A
Taillights, Parking lights, License plate lights, Rear fog light
í
,
For protection of various circuits
8-44
Maintenance and Care
í
Some models.
