Instrument Cluster and Indicators
(Black-out meter)
When the ignition switch is in the ON position, the dashboard gauges illuminate.
1 Speedometer ..............................................................................................................5-24
2 Odometer and Trip Meter ..........................................................................................5-24
3 Tachometer ................................................................................................................5-25
4 Engine Coolant Temperature Gauge..........................................................................5-25
5 Fuel Gauge................................................................................................................ 5-26
6 Instrument Cluster Dimmer Cancel Button (Black-out meter) .................................5-26
Meters and Gauges
