qSide and Curtain Air Bag System Components
(3)
(1)
(1)
(4)
(2)
(1) Side and curtain inflators and air bags
(2) Front seats
(3) Crash sensors and diagnostic modul e (SAS unit)
(4) Side crash sensor
Essential Safety Equipment
SRS Air Bags
2-45
