DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
16 TCM
15A
*1
TCM
10A
*2
17 ENG+B 7.5A PCM, TCM
18 FUEL PUMP 15A Fuel pump
19 IG KEY1 30A Engine control unit, Lighter
20 P.WIND 30A Power window
21 ―― ―
22 DRL 20A DRL
23 ―― ―
24 BLOWER 40A Blower motor
25 BTN 40A Overhead light, Power door lock
26 IG KEY2 40A
Rear wiper motor
í
, Heater control unit, Windshield wiper and
washer
27 DEFOG 40A Rear window defroster
28 ABS 60A ABS
í
29
AD FAN
*1
30A Cooling fan
FAN2
*2
30
FAN
*1
30A Cooling fan
FAN1
*2
31 TAIL 10A Taillights, License plate lights, Parking lights
32 ILLUMI 10A Dashboard illumination
33 MAG 10A Magnet clutch
34 AUDIO 15A Audio system
35 P.SEAT 30A Power seat
í
36 OPENER 7.5A Trunk opener motor
í
37 ―― ―
38
―*1
――
IG1
*2
15A CAT SSR
39 FOG 15A Fog lights
í
40 MAIN 120A For protection of all circuits
*1 2.3-liter engine
*2 3.0-liter engine
8-52
Maintenance and Care
í
Some models.
