13. Attach the layered Form Rubber (B) to the back side of front door module panel, positioning one end at the
break point of butyl tape (A) and along the upper edge of the front door module panel.
14. Prepare 1 set of 2 pieces of cut Form Rubber (D) 10mm X 45mm size.
Piece Sheet Type Sheet Thickness Size Quantity
D Form Rubber 5mm 10mm X 45mm 2
To Next Page
