Bulletin No: 09-036/14
© 2014 Mazda Motor of America, Inc.
Last Issued: 08/29/2014
Page 4 of 16
REPAIR PROCEDURE B
FRONT DOOR
1. Pull both edges of the front glass run channel and remove it from the front door.
2. Apply soap sud to the contacting surface of the new front glass run channel to the front door glass and door
panel
Front Door
Replace the front glass run channel and front sash molding.
Install a Form Rubber to the power outer mirror harness.
Install a Form Rubber between door body panel and module panel.
Install a Urethane Pad to the front door trim.
Rear Door
Replace the inner weather strip and rear beltline molding.
Replace the rear glass run channel and rear sash molding.
Install a urethane pad to the rear door trim.
To Next Page
