3. Disconnect the bulb from the socket.
4. Install the ne w bulb in the reverse order
of removal.
Brake lights/Taillights, Rear turn signal
lights, Reverse lights
1. Pull the center section of the plastic
retainers and remove them, then
remove the trunk end trim.
Removal
Installation
2. On the side the bulb is to be replaced,
pull the center section of the plastic
retainers and remove them, then
remove the trunk side trim.
Removal
Installation
3. Turn the socket and bulb assembly
counterclockwise and remove it.
4. Disconnect the bulb from the socket.
Brake lights/Taillights
Rear turn signal lights
Reverse lights
5. Install the ne w bulb in the reverse order
of removal.
Maintenance and Care
Owner Maintenance
8-41
