qReplacing Interior Light Bulbs
Overhead light
1. Wrap a flathead screwdriver with a soft
cloth to prevent damage to the trim and
gently insert it in the overhead ligh t as
shown in the figure, and then remo ve
the cover.
2. Disconnect the bulb by pulling it out.
3. Install the ne w bulb in the reverse order
of removal.
Trunk light
1. Wrap a flathead screwdriver with a soft
cloth to prevent damage to the trim and
gently insert it in the luggage
compartment light as shown in the
figure, and then remove the luggage
compartment light unit.
2. Disconnect the bulb by pulling it out.
3. Install the ne w bulb in the reverse order
of removal.
8-42
Maintenance and Care
Owner Maintenance
