Convertible Top (Power Retractable Hardtop)
í
The power retractabl e hardtop opens/closes electrically by operating switches in the
vehicle. When opening/cl osing the hardtop, the hardtop, deck and window glass operate
together. The hardtop is stored in the storage area under the deck.
Top latch assembly
Close switch
Open switch
Deck
Indicator light
Hardtop
3-48
Knowing Your Mazda
í
Some models.
