Manual Type
í
Mode selector dial Temperature control dial Fan control dial
Air intake selector
Rear window defroster switch *A/C switch
*Some models
qControl Switches
Temperature control dial
HotCold
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
NOTE
When the mode is set to , or with
the fan control dial in a position other than 0
and the temperature control dial in the
maximum cold position, the air intake selector
switches to the recirculated air mode and the
A/C turns on automatically.
If A/C is not desired, press the A/C switch to
turn it off.
Fan control dial
Slow Fast
6-6
Interior Comfort
í
Some models.
Climate Control System
