3. Pull the center section of the plastic
retainers and remove them, then
remove the trunk end trim.
Removal
Installation
4. Remove the trunk light connector.
5. Remove the trunk lid release lock-out
button co nnector.
6. Pull the center section of the plastic
retainers and remove them, then
remove the trunk side trim.
Removal
Installation
7. Turn the socket and bulb assembly
counterclockwise and remove it.
8. Disconnect the bulb from the socket.
Rear turn signal lights
8-44
Maintenance and Care
Owner Maintenance
