Mazda MX-5 - Instrument Cluster and Display; Meters and Gauges

4 – 24
When Driving
Instrument Cluster and Display
M e t e r s a n d G a u g e s
Type A
Type B
Steering Switch
(With Multi-information Display)
(Without Multi-information Display)
Instrument Cluster

Speedometer ..........................................................................................................page 4-25

Odometer, Trip Meter and Trip Meter Selector ....................................................page 4-25

Tachometer ............................................................................................................page 4-26

Engine Coolant Temperature Gauge .....................................................................page 4-27

Fuel Gauge ............................................................................................................page 4-27

Instrument Panel Illumination ...............................................................................page 4-28

Outside Temperature Display ................................................................................page 4-29

Adjustable Speed Limiter Display ........................................................................page 4-30

Cruise Control Set Vehicle Speed Display ............................................................page 4-30

Trip Computer and INFO Switch ..........................................................................page 4-30

Multi-information Display and INFO Switch .......................................................page 4-33
