If Trouble Arises
When Boot Lid Cannot be Opened
12. Remove the windblocker.
Windblocker
13. Partially peel back the cover on the
right side from the middle of the
vehicle.
14. Pull out the cap and release the boot
lock.
After performing this emergency
measure, have the vehicle inspected at
an expert repairer, we recommend an
Authorised Mazda Repairer as soon as
possible.
CAUTION
Do not pull the screw when pulling the
cap. Otherwise, the screw may fall off
and become lost.
Roof does not operate electrically
1. Remove the aerial if it is installed.
Refer to Aerial on page 5-14 .
2. Lift up the rear roof by hand.
Refer to When the Roof Cannot be
Closed on page 7-60 .
3. Remove the fasteners on the right side
of the vehicle.
To Next Page
