Maintenance and Care
Owner Maintenance
4. Pull the centre of each plastic retainer
and remove the retainers, and then
partially peel back the boot side trim.
Removal
Installation
5. To provide a hole for inserting a ¿ nger
to remove the rear combination lamp
unit later in the procedure, pinch the
top and bottom of the grommet shown
in the ¿ gure and press it out of the hole
in the direction of the rear combination
lamp unit.
Grommet
Rear combination lamp
unit
Grommet
Body
To Next Page
