If Trouble Arises
When the Roof Cannot be Closed
NOTE
If it is dif¿ cult to see the bolt, remove
the windblocker and identify the bolt
from the centre of the vehicle.
Windblocker
3. Turn the L-shaped hexagonal wrench
(Large) anticlockwise to loosen the bolt
slightly.
4. Remove the L-shaped hexagonal
wrench (Large) once from the bolt,
then insert the long end of the wrench
into the bolt.
NOTE
The tip of the long end of the L-shaped
hexagonal wrench can be used at an
angle. Moving the wrench upward
slightly will increase the clearance
between the rear roof and the stored
front roof and facilitate the procedure.
5. Turn the L-shaped hexagonal wrench
(Large) anticlockwise 13 times or more
while pressing the wrench against the
bolt.
NOTE
The bolt cannot be removed
completely.
If it is hard to turn the bolt, repeat
Step 3 a few times.
6. Hook the wire to the link pin shown in
the ¿ gure.
To Next Page
