7
–
69
If Trouble Arises
When the Roof Cannot be Closed
5. One person pushes the rear roof down
and the other person pulls the rope
strongly and straight back towards the
vehicle rear until a click sound is heard.
Rope
NOTE
The rear roof is locked completely if
the position where the rope is hooked
is at the rear end of the bracket
groove in the direction of the vehicle
rear, as shown in the ¿ gure, when
viewed from the vehicle interior.
Rope
Link pin
If the rear roof is not locked
completely, the boot will not open
even if the remote release button
(if equipped), the electric boot lid
opener, or the boot button on the
transmitter is operated.
6. Do the same procedure on the other
side.
7. Open the boot and tie the rope to the
boot hinge.
Hinge
Rope
8. Tie off the other side rope the same
way.
9. Close the boot lid.
After ¿ nishing the procedure
A f t e r ¿ nishing the procedure, have the
roof checked at an Authorised Mazda
Repairer as soon as possible.
WARNING
Drive the vehicle at a speed of 40 km/h
(24 mph) or lower before having the
roof checked at an Authorised Mazda
Repairer:
The front roof may open while the
vehicle is being driven and cause an
accident.
To Next Page
