9
5. Part names
Remote Control
・ Keep the remote control out of the reach of children. Otherwise, they may swallow the
lithium battery accidentally and choke.
・ Do not drop the remote control or hit it against something hard. Otherwise, it can result in
breakdown or malfunction.
・ Pour watering on the remote control, or submerging it, can cause breakdown or
malfunction.
CAUTION
Car find
switch
Registration
switch
Function
Start switch
Stop switch
Key ring
Battery
cover
FFC/IC
Label*
Side Front Back Side
• The location for the controller installation varies depending on the vehicle model.
Not
*<Confirm method of FCC/IC Label>
The FCC/IC label appears when the
Battery Cover is removed.
Antenna
Sends and receives signal
transmission to and from
the remote control.
Rotates 360º.
Back
Controller
Rotates 90º.
Confirm method of FCC/IC Label
To Next Page
