MB Connect Line mbNET MDH 814 User Manual

- 12 -
6 First time operation
Connect,dependingondevicetype,anantenna,andinsertaSIMcard.
BeforeconnectingtheroutertoanetworkorPC,rstensurethatitisproperlyconnected
toapowersupply,otherwiseitmaycausedamagetootherequipment.
•Connectequipotentialbondingtothegroundinglugontherouter’stoppanel.
•Connectthe(10-30VDC)powersupplytotheX1terminaloftherouter.
Achten Sie auf die richtige Polung!
◦ AfterswitchingonthesupplyvoltagethePwrLEDlightsupandthedeviceperforms
asystemcheck.
◦ Afterabout25sec.,bothLEDPwrandLEDErrlightup.
◦ Afteranother25sec.,LEDErrturnso󰀨andtheLEDRdyashes.
◦ Afteratotalofabout90sec.,bothLEDPwrandLEDRdylightup.
ThembNETisnowreadyforoperation.
+ - I4 I3 I2 I1 P M O2 O1
|
X1
|
X2
|
Fc1
Fc3
Rdy
Pwr
Fc2
Fc4
Con
Err
Fc1
Fc3
Rdy
Pwr
Fc2
Fc4
Con
Err
Fc1
Fc3
Rdy
Pwr
Fc2
Fc4
Con
Err
Fc1
Fc3
Rdy
Pwr
Fc2
Fc4
Con
Err
T0 T+25Sek. T+50Sek. T+90Sek.
