Handling
• Never connect the power plug immediately after the device has been taken from a cold to a warm environment.
The resulting condensation could destroy the device.
Allow the device to reach room temperature before connecting it. Wait until the condensation water has
evaporated.
• Never pull on the power cable. Only unplug it by pulling on the intended surfaces of the plug.
• Unplug the power supply if you do not use the device over an extended period of time.
• For safety reasons, disconnect the mains plug from the mains socket in case of a thunderstorm.
• Do not listen to excessively loud music over an extended period of time. This may damage your hearing. This
especially applies when using headphones.
Disposal
At the end of its service life, dispose of the product according to the relevant statutory
regulations.
Technical Data
Model DJ-2650 B USB Model DJ-2650 D USB
Operating voltage 115/230V~60/50Hz 115/230V~60/50Hz
Power consumption 14 W max. 11 W max.
Playback speeds 33-1/3 and 45 rpm 33-1/3 and 45 rpm
Pitch +/-10% +/-10%
Flutter <0.25% (33-1/3 rpm) <0.15% (33-1/3 rpm)
Start- and Stop- times < 1 s < 1 s
Effective pick-up arm length 230.5 mm 230.5 mm
Turntable 332mm 332 mm
Overhang 16mm 16 mm
Weight pick-up system 3.5-8.5 g 3.5-8.5 g
Phono output level 1.5-3.6mV at 1kHz 5cm/s 1.5-3.6mV at 1kHz 5cm/s
Line output level 90-216mV at 1kHz 5cm/s 90-216mV at 1kHz 5cm/s
Tracking force adjustment range 3-4g 3-4g
Dimensions 450 x 350 x 150 mm 450 x 350 x 150 mm
Weight 9 kg 9.9 kg
