48
BioStamp nPoint User Manual
Link Hub and BioStamp Sensor Frequency and Transmission
Specications
Frequency band of reception 2400-2500 MHz
Bandwidth of reception 1 MHz
Frequency band of transmission 2400-2500 MHz
Transmission type
IEEE 802.15.1 direct sequence spread
spectrum (BLE), 0.015 mW EIRP
LED Indicator Messages
Hardware LED Status Indicator Table
For any system or component failures including power failures (indicated by
lack of any lights), please contact the provider for a replacement patient kit.
There is no alarm system.
Power On /
Ready For Use
Charging
Ready to
Apply
Warning/
Failure
Power
O
Link Hub ----- ----- No LEDs
BioStamp
Sensor
(on Link Hub)
(o Link Hub)
No LEDs
No recurring testing is needed during the expected service life.
Link Hub IEC 60127-1 internal fuse rated as F 2A, 63VDC.
Note
