McCulloch MB290 - Assembly Instructions

7
ASSEMBLY INSTRUCTIONS
INSTALL AND REMOVE THE BLOWER TUBE
Install
To install the blower tube, simply push it into the blower
housing. Push it in until the tabs on the top and bottom
of the housing slide into the blower tube detents (Fig. 1).
Remove
To remove the blower tube, use a flat blade screwdriver
to lift the tabs and pull the tube out of the blower
housing (Fig. 1).
Tab
Blower
Tube
To prevent serious
personal injury, stop
the engine and allow the impeller to stop
before attaching or removing tubes.
WARNING:
To prevent serious
personal injury or
damage to the unit, the blower tube must
be installed while operating this unit.
WARNING:
Blower
Tube
Detent
Fig. 1
