McIntosh Audio Control Center C45 - Tuner Antenna Connections; Connecting AM and FM Antennas

28
75ohm FM ANT
(Antenna) connects
to an external FM
antenna or cable
AM ANT (An-
tenna) connector
allows a McIntosh
Remote Antenna to
be connected
RAA1 Remote Antenna can be adjusted to a
position for optimum reception of your fa-
vorite AM stations
Connects with
supplied cable to
the C45
Rear Panel and RAA1 Top Panel Antenna Connections
