PARTS LIST con’t
MA2275
4
6
8
DS4 LED GREEN 5MM HI-INTENSITY 058165
DS5 LED GREEN 5MM HI-INTENSITY 058165
DS6 LED GREEN 5MM HI-INTENSITY 058165
DS7 LED GREEN 5MM HI-INTENSITY 058165
DS9 LED SQUARE RED 058109
DS10 LED SQUARE RED 058109
DS11 LED SQUARE RED 058109
DS12 LED SQUARE RED 058109
DS13 LED SQUARE RED 058109
DS14 LED SQUARE RED 058109
DS15 LED GREEN 5MM HI-INTENSITY 058165
J1 CONN FFC 18PIN 117765
J2 CONN FFC 18PIN 117765
J3 CONN 12 PIN FFC 117720
Q1 TRANSISTOR NPN SILICON 132171
Q2 TRANSISTOR NPN 132223
R1 RES MF 10K 1% 1/4W 144053
R2 RES MF 10 OHM 1% 1/4W 144157
R3 RES NET 10K X8 RES B 144253
R4 RES NETWORK 9X-1-223 144238
R5 RES MF 301 OHM 1% 1/4W 144484
R6 RES MF 301 OHM 1% 1/4W 144484
R7 RES MF 806 OHM 1% 1/4W 144089
R8 RES MF 10K 1% 1/4W 144053
R9 RES MF 324 OHM 1% 1/4W 144338
R10 RES MF 2.21K 1% 1/4W 144298
R11 RES MF 324 OHM 1% 1/4W 144338
R12 RES MF 324 OHM 1% 1/4W 144338
R13 RES MF 324 OHM 1% 1/4W 144338
R15 RES NETWORK 9X-1-223 144238
R16 RES MF 1K 1% 1/4W 144090
R17 RES MF 6.49K 1% 1/4W 144140
R18 RES MF 240 OHM 1% 1/4W 144338
R19 RES MF 240 OHM 1% 1/4W 144338
R20 RES MF 240 OHM 1% 1/4W 144338
R21 RES MF 240 OHM 1% 1/4W 144338
R22 RES MF 100K 1% 1/4W 144113
R23 RES MF 240 OHM 1% 1/4W 144338
R24 RES MF 240 OHM 1% 1/4W 144338
S1 PC BD SWITCH 129294
U1 IC SUPERVISOR WITH EEPROM 133468
U2 IC PROGRAMMED MC2275 V1.00 133523
U3 IC SHFT REG SER-PAR 133186
U4 IC SHFT REG SER-PAR 133186
U5 IC AND 2 INPUT X 4 133175
Y1 RESONATOR CERAMIC 6.0MHZ W/CAP 180039
049967 BALANCED PCB
C1 CAP ELECT 10UF 50V 066445
C2 CAP ELECT 10UF 50V 066445
C3 CAP ELECT 10UF 50V 066445
C4 CAP ELECT 10UF 50V 066445
C5 CAP ELECT 10UF 50V 066445
C6 CAP ELECT 10UF 50V 066445
C7 CAP ELECT 10UF 50V 066445
C8 CAP ELECT 10UF 50V 066445
D1 DIODE SILICON 070047
J1 XLR FEMALE VERTICAL WITH LATCH 117813
J2 XLR FEMALE VERTICAL WITH LATCH 117813
J3 CONN 12 PIN FFC 117720
K1 RELAY REED FORM 1A 5V 500 OHMS 087050
K2 RELAY REED FORM 1A 5V 500 OHMS 087050
K3 RELAY REED FORM 1A 5V 500 OHMS 087050
K4 RELAY REED FORM 1A 5V 500 OHMS 087050
R1 RES NETWORK 2X220K ISO 144262
R2 RES NETWORK 2X220K ISO 144262
R3 RES NETWORK 2X220K ISO 144262
R4 RES NETWORK 2X220K ISO 144262
049968 VOLUME/TONE PCB
C1 CAP ELECT 10UF 50V 066445
C2 CAP ELECT 47UF 35V 066446
C3 CAP MONO 100PF 100V 10% NPO 061300
C4 CAP MONO 100PF 100V 10% NPO 061300
C5 CAP MONO .1uF 50V 20% Z5U 061305
C6 CAP MONO .1uF 50V 20% Z5U 061305
C7 CAP ELECT 10UF 50V 066445
C8 CAP ELECT 47UF 35V 066446
C9 CAP MONO 100PF 100V 10% NPO 061300
C10 CAP MONO 100PF 100V 10% NPO 061300
C11 CAP ELECT 220UF 50V 20% 066254
C12 CAP ELECT 47UF 10V BP 066378
C13 CAP ELECT 22UF 100V 066506
C14 CAP MPF 0.033UF 5% 63VDC 064318
C15 CAP MONO .1uF 50V 20% Z5U 061305
C16 CAP MONO .1uF 50V 20% Z5U 061305
C17 CAP MPF 0.033UF 5% 63VDC 064318
C18 CAP ELECT 22UF 100V 066506
C19 CAP MPF 0.033UF 5% 63VDC 064318
C20 CAP MPF 0.033UF 5% 63VDC 064318
C42 CAP ELECT 220UF 25V 066507
D1 DIODE SILICON 070047
J1 CONN 23 PIN FFC 117715
K1 RELAY REED FORM 1A 5V 500 OHMS 087050
K2 RELAY REED FORM 1A 5V 500 OHMS 087050
K3 RELAY REED FORM 1A 5V 500 OHMS 087050
K4 RELAY REED FORM 1A 5V 500 OHMS 087050
R1 POT 50KAX2 134490
R2 RES MF 1K 1% 1/4W 144090
R3 RES MF 3.32K 1% 1/4W 144095
R4 POT BALANCE 2KOHM 134464
R5 RES MF 475K 1% 1/4W 144364
R6 RES MF 1K 1% 1/4W 144090
R7 RES MF 475K 1% 1/4W 144364
R8 RES MF 3.32K 1% 1/4W 144095
R9 RES MF 10 OHM 1% 1/4W 144157
R10 RES MF 10 OHM 1% 1/4W 144157
R11 RES MF 10 OHM 1% 1/4W 144157
R12 RES MF 10 OHM 1% 1/4W 144157
R13 RES MF 681 OHM 1% 1/4W 144195
R14 RES MF 1M 1/4W 144269
R15 RES MF 100K 1% 1/4W 144113
R16 RES MF 475 OHM 1% 1/4W 144086
R17 POTENTIOMETER 134457
R18 POTENTIOMETER 134457
R19 RES MF 1M 1/4W 144269
R20 RES MF 681 OHM 1% 1/4W 144195
R21 RES MF 1M 1/4W 144269
R22 RES MF 100K 1% 1/4W 144113
R23 RES MF 475 OHM 1% 1/4W 144086
R24 RES MF 1M 1/4W 144269
R25 RES MF 1K 1% 1/4W 144090
R26 RES MF 1K 1% 1/4W 144090
R53 RES MF 10 OHM 1% 1/4W 144157
U1 IC DUAL OPERATIONAL AMPLIFIER 133260
U2 IC OPAMP NE4558N 133028
U7 IC DC MOTOR DRIVER 133191
049969 DATA PCB
C1 CAP MONO .1uF 50V 20% Z5U 061305
C2 CAP MONO 1000PF 50V 10% NPO 061303
C3 CAP MONO .1uF 50V 20% Z5U 061305
C4 CAP MONO .1uF 50V 20% Z5U 061305
C5 CAP MONO 220PF 100V 10% NPO 061301
D1 DIODE SILICON 070047
D2 DIODE SILICON 070047
D3 DIODE SILICON 070047
J1 JACK HEADPHONE STEREO 1/8IN 117759
J2 JACK HEADPHONE STEREO 1/8IN 117759
J3 JACK HEADPHONE STEREO 1/8IN 117759
J4 JACK HEADPHONE STEREO 1/8IN 117759
J5 JACK HEADPHONE STEREO 1/8IN 117759
J6 JACK HEADPHONE STEREO 1/8IN 117759
J7 JACK HEADPHONE STEREO 1/8IN 117759
J8 CONN 12 PIN FFC 117720
J9 CONN GOLD F RIGHT ANGLE 117661
J10 JACK HEADPHONE STEREO 1/8IN 117759
J11 JACK HEADPHONE STEREO 1/8IN 117759
R1 RES MF 100 OHM 1% 1/4W 144196
R2 RES MF 100 OHM 1% 1/4W 144196
R3 RES MF 1K 1% 1/4W 144090
R4 RES MF 100 OHM 1% 1/4W 144196
R5 RES MF 1K 1% 1/4W 144090
R6 RES MF 1K 1% 1/4W 144090
R7 RES MF 100 OHM 1% 1/4W 144196
R8 RES MF 100 OHM 1% 1/4W 144196
R9 RES MF 100 OHM 1% 1/4W 144196
R10 RES MF 100 OHM 1% 1/4W 144196
R11 RES MF 1K 1% 1/4W 144090
R12 RES MF 10 OHM 1% 1/4W 144157
R13 RES MF 221 OHM 1% 1/4W 144172
R14 RES MF 61.9K OHM 1/4W 144335
R15 RES MF 10 OHM 1% 1/4W 144157
R16 RES MF 22.1K 1% 1/4W 144187
R17 RES MF 182 OHM 1/4W 1% 144273
R18 RES MF 182 OHM 1/4W 1% 144273
R19 RES MF 2.21K 1% 1/4W 144298
R20 RES MF 182 OHM 1/4W 1% 144273
R21 RES MF 182 OHM 1/4W 1% 144273
R22 RES MF 2.21K 1% 1/4W 144298
R23 RES MF 2.21K 1% 1/4W 144298
SP1 BRACKET PCB CARD MOUNTING 003611
SP2 BRACKET PCB CARD MOUNTING 003611
U1 IC SHFT REG SER-PAR 133186
U2 IC 8 LN DRIVER ARRAY 133180
U3 IC OPERATIONAL AMPLIFIER 133189
U4 IC AND 2 INPUT X 4 133175
049970 PUSHBUTTON PCB
C1 CAP MONO .1uF 50V 20% Z5U 061305
C2 CAP ELECT 47UF 16V 6.3X5 CASE 066380
DS1 LED SQUARE RED 058109
DS2 LED SQUARE RED 058109
DS3 LED SQUARE RED 058109
DS4 LED SQUARE RED 058109
DS5 LED SQUARE RED 058109
DS8 LED ARRAY(4) YELLOW SQUARE 058126
J1 CONN FFC 18PIN 117765
J2 JACK PHONO 1/8 STEREO VER 117462
MT1 SENSOR IR 38KHZ 121046
R1 RES MF 324 OHM 1% 1/4W 144338
R2 RES MF 100 OHM 1% 1/4W 144196
R14 RES MF 499 1% 1/4W 144087
S1 SWITCH PB TACT 150058
S2 SWITCH PB TACT 150058
S3 SWITCH PB TACT 150058
S4 SWITCH PB TACT 150058
S5 SWITCH PB TACT 150058
049971 AMPLIFIER PCB
C1 CAP MONO 220PF 100V 10% NPO 061301
C2 CAP ELECT 470UF 16V 066508
C3 CAP MONO .1uF 50V 20% Z5U 061305
C4 CAP MONO .1uF 50V 20% Z5U 061305
C5 CAP POLYPROP 0.22UF 20% 1KVDC 064432
C6 CAP POLYPROP 0.22UF 20% 1KVDC 064432
C7 CAP MONO 100PF 100V 10% NPO 061300
C8 CAP MONO 100PF 100V 10% NPO 061300
C10 CAP ELECT 470UF 16V 066508
C11 CAP ELECT 10UF 50V 066445
F1 FUSE T 0.4A 250V 089108
J1 CONN 12 PIN FFC 117720
J2 BLADE FASTON W/FEET 117708
J3 BLADE FASTON W/FEET 117708
J4 BLADE FASTON W/FEET 117708
J5 BLADE FASTON W/FEET 117708
J6 BLADE FASTON W/FEET 117708
J7 CONN PCB MOUNT POWER RED 117719
J9 BLADE FASTON W/FEET 117708
L1 CHOKE 2.2mH 122001
L2 CHOKE 2.2mH 122001
Q2 TRANSISTOR N JFET 132222
Q3 TRANSISTOR NPN 132136
Q4 TRANSISTOR NPN 132136
Q5 TRANSISTOR NPN 132136
Q6 TRANSISTOR NPN 132136
Q7 TRANSISTOR N JFET 132222
Q8 TRANSISTOR N JFET 132222
Q9 TRANSISTOR N JFET 132222
R5 RES MF 2.21M 1/4W 144265
R6 RES MF 10K 1% 1/4W 144053
R7 RES MF 1.82K 1% 1/4W 144296
R8 RES MF 40.2K 1% 1/4W 144107
R9 RES MF 10K 1% 1/4W 144053
R10 RES MF 2.21M 1/4W 144265
R11 RES MF 2.74K 1% 1/4W 144304
R12 RES MO 46.4k 1% 1W 144436
R13 RES MO 46.4k 1% 1W 144436
R14 RES MF 10K 1% 1/4W 144053
R15 RES MF 121K 1% 1/4W 144418
R16 RES MF 47.5K 1% 1/4W 144108
R17 RES MF 1K 1% 1/4W 144090
R19 RES MF 1M 1/4W 144269
R20 RES MF 1M 1/4W 144269
R21 RES MF 332k 1% .5W 144355
R22 RES MO 100K 5% 2W 144438
R23 RES MO 100K 5% 2W 144438
R24 RES MO 100K 5% 2W 144438
R25 RES MO 100K 5% 2W 144438
R27 RES WW 220 OHM 10% 5W 139009
R28 RES WW 220 OHM 10% 5W 139009
R30 RES MF 17.4K 1% 1/4W 144413
