PERFORMANCE SPECIFICATIONS
2
1. The heavy notes on the schematic denote the primary
signal path.
2. Unless otherwise noted, all voltages indicated on the
schematics are measured under the following conditions:
a. AC input at 120 volts, 50/60Hz.
b. All voltages are +/-10% with respect to ground. A
high impedance (10 megaohm) voltmeter must be used.
3. Unless otherwise specified:
a. Resistor values are in ohms.
b. Capacitor values are microfarads (uF).
c. Inductor values are in microhenries (uH).
4. On PC board drawings, Square pad indicates:
a. Polarized Capacitors - Positive
b. Diodes - Cathode
c. Others - Pin 1
5. WARNING
Parts marked with the symbol have critical
characteristics. Use only replacement parts recom-
mended by the manufacturer.
MusicBank
TM
is a registered trademark of the Nakamichi Corporation
NOTES
Digital Audio Format
IEC958, S/PDIF
Digital Outputs
Optical: -15!
""
""
" -20dBm
Coaxial: 0.5V p-p @ 75ohms
XRL: 5V p-p @ 110ohms (AES/EBU)
Transport
Pickup: Optical 3-beam laser
Objective Lens Drive System: 2-Dimensional parallel
Laser Type: GaAIAs semiconductor
Laser Beam Wavelength: 780nm
Digital Signal Format
Sampling Frequency: 44.1kHz
Quantization Bit: 16-bit linear/channel
Modulation Code: Eight to Fourteen Modulation
Error Correction: Cross Interleave Reed Solomon
Power Requirements
100 Volts, 50/60Hz at 20 watts
110 Volts, 50/60Hz at 20 watts
120 Volts, 50/60Hz at 20 watts
220 Volts, 50/60Hz at 20 watts
230 Volts, 50/60Hz at 20 watts
240 Volts, 50/60Hz at 20 watts
Note: Refer to the rear panel of the MCD1000 for the
correct voltage.
Dimensions
Front Panel: 17-1/2 inches (44.5cm) wide, 6 inches
(15.24cm) high (including feet). Depth is 16-1/8
inches (40.96cm) including the Front Panel and
knobs.
Weight
27.5 pounds (12.47g) net, 41.5 pounds (18.83kg) in
shipping carton
