PARTS LIST con’t
3
MOLD13 INDICATOR LED MOLD 017715
MOLD14 FUNCTION LED MOLD 017714
R15 RES MF 4.99K 1% 1/4W 144098
R18 RES MF 4.99K 1% 1/4W 144098
KEYBOARD PCB 050053
C13 CAP MONO .1uF 50V 20% Z5U 061305
C24 CAP ELECT 47UF 35V 066446
DS11 LED SQUARE RED 058109
DS12 LED SQUARE RED 058109
DS36 LED SQUARE RED 058109
J2 CONN FFC 18PIN 117765
R16 RES MF 100 OHM 1% 1/4W 144196
R17 RES MF 332 OHM 1/4W 144446
S1 SWITCH PB TACT 150059
S2 SWITCH PB TACT 150059
S5 SWITCH PB TACT 150058
S7 SWITCH PB TACT 150058
S9 SWITCH PB TACT 150058
S10 SWITCH PB TACT 150058
S11 SWITCH PB TACT 150058
S12 SWITCH PB TACT 150058
S13 SWITCH PB TACT 150058
S14 SWITCH PB TACT 150058
S15 SWITCH PB TACT 150058
S16 SWITCH PB TACT 150058
S17 SWITCH SLIDE 148059
SENSOR SENSOR IR 38KHZ 121046
SURROUND PCB 050037
C1 CAP ELECT 220UF 50V 20% 066254
C2 CAP ELECT 100UF 25V 066529
C3 CAP MONO .1uF 50V 20% Z5U 061305
C4 CAP MONO .1uF 50V 20% Z5U 061305
C5 CAP MONO .1uF 50V 20% Z5U 061305
C6 CAP MONO .1uF 50V 20% Z5U 061305
C7 CAP MONO .1uF 50V 20% Z5U 061305
C8 CAP MONO .1uF 50V 20% Z5U 061305
C9 CAP MONO .1uF 50V 20% Z5U 061305
C10 CAP MONO .1uF 50V 20% Z5U 061305
C11 CAP MONO .1uF 50V 20% Z5U 061305
C12 CAP MONO .1uF 50V 20% Z5U 061305
C13 CAP MONO .1uF 50V 20% Z5U 061305
C14 CAP MONO .1uF 50V 20% Z5U 061305
C15 CAP MONO .1uF 50V 20% Z5U 061305
C16 CAP MONO 22PF 200V 10% NPO 061298
C18 CAP MONO .1uF 50V 20% Z5U 061305
C19 CAP MONO .1uF 50V 20% Z5U 061305
C20 CAP MONO .1uF 50V 20% Z5U 061305
C21 CAP MONO .1uF 50V 20% Z5U 061305
C22 CAP MONO .1uF 50V 20% Z5U 061305
C23 CAP MONO .1uF 50V 20% Z5U 061305
C24 CAP MONO .1uF 50V 20% Z5U 061305
C25 CAP MONO .1uF 50V 20% Z5U 061305
C26 CAP MONO .1uF 50V 20% Z5U 061305
C27 CAP MONO .1uF 50V 20% Z5U 061305
C28 CAP MONO .1uF 50V 20% Z5U 061305
C29 CAP MONO .1uF 50V 20% Z5U 061305
C30 CAP MONO .1uF 50V 20% Z5U 061305
C32 CAP MONO .1uF 50V 20% Z5U 061305
C36 CAP MONO 22PF 200V 10% NPO 061298
C37 CAP MONO 22PF 200V 10% NPO 061298
C38 CAP MONO 22PF 200V 10% NPO 061298
C39 CAP MONO 22PF 200V 10% NPO 061298
C40 CAP MONO 22PF 200V 10% NPO 061298
C41 CAP MONO 22PF 200V 10% NPO 061298
C42 CAP MONO 22PF 200V 10% NPO 061298
C43 CAP MONO 22PF 200V 10% NPO 061298
C44 CAP MONO 22PF 200V 10% NPO 061298
C45 CAP MONO 22PF 200V 10% NPO 061298
C46 CAP MONO 22PF 200V 10% NPO 061298
C47 CAP MONO 22PF 200V 10% NPO 061298
C48 CAP MONO 22PF 200V 10% NPO 061298
C49 CAP MONO 22PF 200V 10% NPO 061298
C50 CAP MONO 22PF 200V 10% NPO 061298
C53 CAP ELECT 3300UF 35V 066509
C55 CAP ELECT 3300UF 35V 066509
C56 CAP ELECT 3300UF 35V 066509
C58 CAP ELECT 18000UF 16V 066460
C59 CAP ELECT 10UF 50V 066445
C60 CAP ELECT 10UF 50V 066445
C61 CAP ELECT 10UF 16V 4X5 CASE 066382
C62 CAP ELECT 10UF 16V 4X5 CASE 066382
C65 CAP ELECT 10UF 16V 4X5 CASE 066382
C66 CAP ELECT 10UF 16V 4X5 CASE 066382
C67 CAP ELECT 10UF 16V 4X5 CASE 066382
C68 CAP ELECT 10UF 16V 4X5 CASE 066382
C69 CAP ELECT 10UF 16V 4X5 CASE 066382
C70 CAP ELECT 10UF 16V 4X5 CASE 066382
C71 CAP ELECT 10UF 16V 4X5 CASE 066382
C72 CAP ELECT 10UF 16V 4X5 CASE 066382
C73 CAP ELECT 10UF 16V 4X5 CASE 066382
C77 CAP ELECT 10UF 16V 4X5 CASE 066382
C79 CAP ELECT 10UF 16V 4X5 CASE 066382
C80 CAP ELECT 10UF 16V 4X5 CASE 066382
C81 CAP ELECT 10UF 16V 4X5 CASE 066382
C82 CAP ELECT 10UF 16V 4X5 CASE 066382
C83 CAP ELECT 10UF 16V 4X5 CASE 066382
C84 CAP ELECT 10UF 16V 4X5 CASE 066382
C85 CAP ELECT 10UF 16V 4X5 CASE 066382
C86 CAP ELECT 10UF 16V 4X5 CASE 066382
C87 CAP ELECT 10UF 16V 4X5 CASE 066382
C88 CAP ELECT 10UF 16V 4X5 CASE 066382
C89 CAP ELECT 10UF 16V 4X5 CASE 066382
C94 CAP ELECT 10UF 16V 4X5 CASE 066382
C95 CAP ELECT 10UF 16V 4X5 CASE 066382
C96 CAP ELECT 10UF 16V 4X5 CASE 066382
C97 CAP ELECT 10UF 16V 4X5 CASE 066382
C98 CAP MONO 100PF 100V 10% NPO 061300
C99 CAP MONO 100PF 100V 10% NPO 061300
C100 CAP ELECT 10UF 16V 4X5 CASE 066382
C101 CAP ELECT 10UF 16V 4X5 CASE 066382
C102 CAP ELECT 10UF 16V 4X5 CASE 066382
C103 CAP ELECT 10UF 16V 4X5 CASE 066382
C104 CAP ELECT 10UF 16V 4X5 CASE 066382
C105 CAP ELECT 10UF 16V 4X5 CASE 066382
C106 CAP ELECT 10UF 16V 4X5 CASE 066382
C107 CAP ELECT 10UF 16V 4X5 CASE 066382
C110 CAP MONO .1uF 50V 20% Z5U 061305
C111 CAP MONO .1uF 50V 20% Z5U 061305
C113 CAP MONO .1uF 50V 20% Z5U 061305
C114 CAP MONO .1uF 50V 20% Z5U 061305
C115 CAP MONO .1uF 50V 20% Z5U 061305
C116 CAP MONO .1uF 50V 20% Z5U 061305
C119 CAP MONO .1uF 50V 20% Z5U 061305
C120 CAP MONO .1uF 50V 20% Z5U 061305
C121 CAP MPF 0.0022UF 5% 63VDC 064304
C128 CAP ELECT 1000UF 25V 066404
C129 CAP MONO .1uF 50V 20% Z5U 061305
C130 CAP MONO .1uF 50V 20% Z5U 061305
C131 CAP MONO .1uF 50V 20% Z5U 061305
C132 CAP MPF 0.0022UF 5% 63VDC 064304
C133 CAP MONO .1uF 50V 20% Z5U 061305
C134 CAP MONO .1uF 50V 20% Z5U 061305
C135 CAP MPF 0.0022UF 5% 63VDC 064304
C137 CAP MPF 0.1UF 5% 63VDC 064325
C138 CAP MPF 0.047UF 5% 63VDC 064320
C139 CAP MPF 0.047UF 5% 63VDC 064320
C140 CAP MPF 0.1UF 5% 63VDC 064325
C141 CAP MPF 0.047UF 5% 63VDC 064320
C142 CAP MPF 0.047UF 5% 63VDC 064320
C143 CAP MPF 0.047UF 5% 63VDC 064320
C144 CAP MPF 0.047UF 5% 63VDC 064320
C151 CAP MONO .1uF 50V 20% Z5U 061305
C153 CAP MONO 22PF 200V 10% NPO 061298
C154 CAP MONO 100PF 100V 10% NPO 061300
C155 CAP MONO 22PF 200V 10% NPO 061298
C156 CAP MONO 22PF 200V 10% NPO 061298
C157 CAP MONO 22PF 200V 10% NPO 061298
C158 CAP MONO 22PF 200V 10% NPO 061298
C159 CAP MONO 22PF 200V 10% NPO 061298
C160 CAP MONO 22PF 200V 10% NPO 061298
C161 CAP MONO 22PF 200V 10% NPO 061298
C162 CAP MONO 100PF 100V 10% NPO 061300
C167 CAP MONO 22PF 200V 10% NPO 061298
C168 CAP MONO 100PF 100V 10% NPO 061300
C169 CAP MONO 22PF 200V 10% NPO 061298
C170 CAP ELECT 100UF 25V 066529
C171 CAP ELECT 100UF 25V 066529
C172 CAP ELECT 100UF 25V 066529
C174 CAP ELECT 100UF 25V 066529
C175 CAP ELECT 1000UF 25V 066404
C178 CAP MPF 0.1UF 100V 064338
C180 CAP MONO 47PF 200V 10% NPO 061299
C181 CAP MONO 47PF 200V 10% NPO 061299
C182 CAP MONO 47PF 200V 10% NPO 061299
C183 CAP MONO 47PF 200V 10% NPO 061299
C184 CAP MONO 47PF 200V 10% NPO 061299
C185 CAP MONO 47PF 200V 10% NPO 061299
C186 CAP MPF 0.1UF 100V 064338
C188 CAP MPF 0.1UF 100V 064337
C189 CAP MPF 0.1UF 100V 064337
C192 CAP MPF 0.1UF 100V 064337
C193 CAP MPF 0.1UF 100V 064337
C194 CAP ELECT 470UF 50V 066469
C195 CAP ELECT 470UF 50V 066469
C196 CAP MONO 22PF 200V 10% NPO 061298
C197 CAP MONO 22PF 200V 10% NPO 061298
C198 CAP MONO 22PF 200V 10% NPO 061298
C199 CAP MONO 22PF 200V 10% NPO 061298
C200 CAP ELECT 10UF 16V 4X5 CASE 066382
C201 CAP MONO 22PF 200V 10% NPO 061298
C202 CAP MONO 47PF 200V 10% NPO 061299
C203 CAP ELECT 10UF 16V 4X5 CASE 066382
C204 CAP MONO 22PF 200V 10% NPO 061298
C205 CAP MONO 22PF 200V 10% NPO 061298
C206 CAP MONO 1000PF 50V 10% NPO 061303
C215 CAP ELECT 10UF 16V 4X5 CASE 066382
C220 CAP ELECT 10UF 16V 4X5 CASE 066382
C221 CAP ELECT 10UF 16V 4X5 CASE 066382
C236 CAP MONO .1uF 50V 20% Z5U 061305
C238 CAP MONO .01UF 50V 20% X7R 061304
C239 CAP MONO .01UF 50V 20% X7R 061304
C250 CAP MONO 22PF 200V 10% NPO 061298
C251 CAP MONO 47PF 200V 10% NPO 061299
C254 CAP MONO .1uF 50V 20% Z5U 061305
C255 CAP MONO .1uF 50V 20% Z5U 061305
C256 CAP ELECT 10UF 16V 4X5 CASE 066382
C257 CAP ELECT 10UF 16V 4X5 CASE 066382
C258 CAP MONO 22PF 200V 10% NPO 061298
C259 CAP MONO 22PF 200V 10% NPO 061298
C260 CAP MONO 22PF 200V 10% NPO 061298
C261 CAP MONO 22PF 200V 10% NPO 061298
C262 CAP ELECT 10UF 16V 4X5 CASE 066382
