IC4 IC AND 2 INPUT X 4 133175
IC5 IC SHFT REG SER-PAR 133186
IC6 IC SHFT REG SER-PAR 133186
IC7 IC SHFT REG SER-PAR 133186
IC8 IC SHFT REG SER-PAR 133186
IC9 IC SHFT REG SER-PAR 133186
IC10 IC 8 LN DRIVER ARRAY 133180
IC11 IC 8 LN DRIVER ARRAY 133180
IC12 IC 8 LN DRIVER ARRAY 133180
IC23 IC LINE RECEIVER, QUAD 133428
IC24 IC 2 INPUT X 4 133167
IC25 IC HEX UNBUF INVERTER 133173
IC35 IC 8 LN DRIVER ARRAY 133180
IC40 IC 8-INPUT SEL/MULTI 133219
J1 CONN MALE 7 PIN 117217
J2 CONN 4 PIN 117215
J3 CONN MALE 6 POS FRICTION LOCK 117218
J4_ CONN 11 POS MALE 117279
J5_ CONN MALE 9 POS FRICTION LOCK 117244
J8 JACK MINI 117494
J9 JACK MINI 117494
J10 JACK MINI 117494
J11 JACK MINI 117494
J12 JACK MINI 117494
J13 JACK MINI 117494
J14 JACK MINI 117494
J15 JACK MINI 117494
J16 JACK MINI 117494
J17 JACK MINI 117494
J18 JACK MINI 117494
J19 JACK MINI 117494
J20 JACK MINI 117494
J21 JACK MINI 117494
J22 JACK MINI 117494
J30 CONN 4 PIN 117215
J32 CONN MALE 7 PIN 117217
J36 JACK RCA 4X11 ORANGE 14MM 117778
J37 CONN MALE 10 POS RIGHT ANGLE 117260
L1 CHOKE 3.9uH 5%-10% 122255
L2 CHOKE 18uH 5%-10% 122224
L3 CHOKE 18uH 5%-10% 122224
L4 CHOKE 18uH 5%-10% 122224
L5 CHOKE 18uH 5%-10% 122224
L6 CHOKE 18uH 5%-10% 122224
L7 CHOKE 18uH 5%-10% 122224
L8 CHOKE 18uH 5%-10% 122224
L9 CHOKE 18uH 5%-10% 122224
L10 CHOKE 18uH 5%-10% 122224
OPT1 FIBER OPTIC RECEIVER 058156
OPT2 FIBER OPTIC RECEIVER 058156
OPT3 FIBER OPTIC RECEIVER 058156
OPT4 TRANSMITTER FIBER OPTIC 058157
R1 RES NETWORK 5 X 100 ISO 144260
R2 RES NETWORK 5 X 100 ISO 144260
R3 RES NETWORK 5 X 100 ISO 144260
R5 RES MF 100K 1% 1/4W 144113
R6 RES MF 100K 1% 1/4W 144113
R7 RES MF 100K 1% 1/4W 144113
R8 RES MF 100K 1% 1/4W 144113
R10 RES MF 100K 1% 1/4W 144113
R11 RES MF 100K 1% 1/4W 144113
R20 RES MF 1K 1% 1/4W 144090
R30 RES MF 75 OHM 1% 1/4W 144444
R31 RES MF 75 OHM 1% 1/4W 144444
R32 RES MF 75 OHM 1% 1/4W 144444
R33 RES MF 365 OHM 1% 1/4W 144071
R34 RES MF 95.3 OHM 1% 1/4W 144220
R40 RES MF 10K 1% 1/4W 144053
R60 RES MF 100K 1% 1/4W 144113
R61 RES MF 1K 1% 1/4W 144090
R63 RES MF 100K 1% 1/4W 144113
T 1 TRANSFORMER DIGITAL INTERFACE 159285
U1 IC REGULATOR 12V 133156
S-VIDEO PCB 050035
C3 CAP MONO .1uF 50V 20% Z5U 061305
C4 CAP MONO .1uF 50V 20% Z5U 061305
C7 CAP MONO .1uF 50V 20% Z5U 061305
C8 CAP MONO .1uF 50V 20% Z5U 061305
C9 CAP MONO .1uF 50V 20% Z5U 061305
C10 CAP MONO .1uF 50V 20% Z5U 061305
C11 CAP MONO .1uF 50V 20% Z5U 061305
C13 CAP MONO .1uF 50V 20% Z5U 061305
C14 CAP MONO .1uF 50V 20% Z5U 061305
C15 CAP MONO .1uF 50V 20% Z5U 061305
C16 CAP ELECT 10UF 50V 066445
C17 CAP ELECT 10UF 50V 066445
C21 CAP MONO .1uF 50V 20% Z5U 061305
C22 CAP MONO .1uF 50V 20% Z5U 061305
C24 CAP MONO .1uF 50V 20% Z5U 061305
C26 CAP MONO .1uF 50V 20% Z5U 061305
C29 CAP MONO .1uF 50V 20% Z5U 061305
C30 CAP MONO .1uF 50V 20% Z5U 061305
C31 CAP MONO .1uF 50V 20% Z5U 061305
C32 CAP MONO .1uF 50V 20% Z5U 061305
C34 CAP MONO .1uF 50V 20% Z5U 061305
C36 CAP MONO .1uF 50V 20% Z5U 061305
C46 CAP MONO .1uF 50V 20% Z5U 061305
C47 CAP ELECT 10UF 50V 066445
C48 CAP ELECT 10UF 50V 066445
C49 CAP ELECT 10UF 50V 066445
C50 CAP ELECT 10UF 50V 066445
C51 CAP ELECT 10UF 50V 066445
C54 CAP ELECT 10UF 50V 066445
C59 CAP MONO .1uF 50V 20% Z5U 061305
C60 CAP MONO .1uF 50V 20% Z5U 061305
C61 CAP MONO .1uF 50V 20% Z5U 061305
C68 CAP MONO .1uF 50V 20% Z5U 061305
C70 CAP MONO .1uF 50V 20% Z5U 061305
C71 CAP MONO .1uF 50V 20% Z5U 061305
C72 CAP MONO .1uF 50V 20% Z5U 061305
C73 CAP MONO .1uF 50V 20% Z5U 061305
C74 CAP ELECT 47UF 25V 20% NP 066378
C75 CAP ELECT 47UF 25V 20% NPP 066378
C76 CAP ELECT 47UF 25V 20% NP 066378
C77 CAP ELECT 47UF 25V 20% NP 066378
C78 CAP ELECT 47UF 25V 20% NP 066378
C79 CAP ELECT 47UF 25V 20% NP 066378
C80 CAP MONO 220PF 100V 10% NPO 061301
C81 CAP MONO 220PF 100V 10% NPO 061301
C90 CAP ELECT 47UF 25V 20% NP 066378
C91 CAP ELECT 47UF 25V 20% NP 066378
D5 DIODE SIL SIGNAL 400MA 070098
D6 DIODE SIL SIGNAL 400MA 070098
IC1 IC SPST QUAD FET SWITCHES N O 133426
IC2 IC SPST QUAD FET SWITCHES N O 133426
IC3 IC SPST QUAD FET SWITCHES N O 133426
IC4 IC SPST QUAD FET SWITCHES N O 133426
IC5 IC SPST QUAD FET SWITCHES N O 133426
IC6 IC SPST QUAD FET SWITCHES N O 133426
IC7 IC SPST QUAD FET SWITCHES N O 133426
IC8 IC SPST QUAD FET SWITCHES N O 133426
IC9 IC SPST QUAD FET SWITCHES N O 133426
IC10 IC SPST QUAD FET SWITCHES N O 133426
IC17 IC SPST QUAD FET SWITCHES N O 133426
IC18 IC SPST QUAD FET SWITCHES N O 133426
IC19 IC SPST QUAD FET SWITCHES N O 133426
IC20 IC SHFT REG SER-PAR 133186
IC21 IC SHFT REG SER-PAR 133186
IC22 IC SHFT REG SER-PAR 133186
IC30 IC SHFT REG SER-PAR 133186
IC31 IC SHFT REG SER-PAR 133186
J1 JACK S-VIDEO 3X1 14MM 117779
J2 JACK S-VIDEO 3X1 14MM 117779
J3 JACK S-VIDEO 3X1 14MM 117779
J4 JACK S-VIDEO 3X1 14MM 117779
J5 JACK S-VIDEO 3X1 14MM 117779
J20 CONN MALE 10 POS RIGHT ANGLE 117260
J23 CONN MALE 6 POS FRICTION LOCK 117218
J25_ CONN 4 PIN 117215
Q1 TRANSISTOR NPN 132223
R1 RES MF 75 OHM 1% 1/4W 144444
R2 RES MF 75 OHM 1% 1/4W 144444
R3 RES MF 75 OHM 1% 1/4W 144444
R4 RES MF 75 OHM 1% 1/4W 144444
R5 RES MF 75 OHM 1% 1/4W 144444
R6 RES MF 806 OHM 1% 1/4W 144089
R7 RES MF 75 OHM 1% 1/4W 144444
R8 RES MF 75 OHM 1% 1/4W 144444
R9 RES MF 75 OHM 1% 1/4W 144444
R10 RES MF 75 OHM 1% 1/4W 144444
R11 RES MF 806 OHM 1% 1/4W 144089
R12 RES MF 75 OHM 1% 1/4W 144444
R13 RES MF 75 OHM 1% 1/4W 144444
R14 RES MF 75 OHM 1% 1/4W 144444
R15 RES MF 806 OHM 1% 1/4W 144089
R16 RES MF 75 OHM 1% 1/4W 144444
R17 RES MF 75 OHM 1% 1/4W 144444
R18 RES MF 75 OHM 1% 1/4W 144444
R19 RES MF 75 OHM 1% 1/4W 144444
R20 RES MF 75 OHM 1% 1/4W 144444
R21 RES MF 10K 1% 1/4W 144053
R22 RES MF 806 OHM 1% 1/4W 144089
R23 RES MF 806 OHM 1% 1/4W 144089
R24 RES MF 10K 1% 1/4W 144053
R25 RES MF 75 OHM 1% 1/4W 144444
R26 RES MF 10K 1% 1/4W 144053
R27 RES MF 806 OHM 1% 1/4W 144089
R28 RES MF 806 OHM 1% 1/4W 144089
R29 RES MF 806 OHM 1% 1/4W 144089
R30 RES MF 75 OHM 1% 1/4W 144444
R31 RES MF 10K 1% 1/4W 144053
R32 RES MF 75 OHM 1% 1/4W 144444
R33 RES MF 75 OHM 1% 1/4W 144444
R34 RES MF 10K 1% 1/4W 144053
R35 RES MF 75 OHM 1% 1/4W 144444
R36 RES MF 806 OHM 1% 1/4W 144089
R37 RES MF 806 OHM 1% 1/4W 144089
R38 RES MF 806 OHM 1% 1/4W 144089
R39 RES MF 10K 1% 1/4W 144053
R40 RES MF 806 OHM 1% 1/4W 144089
R49 RES FP 10 OHM 5% 1/4W 137025
R50 RES FP 10 OHM 5% 1/4W 137025
R51 RES FP 10 OHM 5% 1/4W 137025
R52 RES FP 10 OHM 5% 1/4W 137025
R54 RES FP 10 OHM 5% 1/4W 137025
R56 RES FP 10 OHM 5% 1/4W 137025
R60 RES NETWORK 8X47KI 144457
R61 RES NETWORK 8X47KI 144457
R62 RES NETWORK 8X47KI 144457
R63 RES NETWORK 8X47KI 144457
R67 RES FP 10 OHM 5% 1/4W 137025
R68 RES MF 75 OHM 1% 1/4W 144444
R69 RES MF 75 OHM 1% 1/4W 144444
R70 RES MF 75 OHM 1% 1/4W 144444
5
PARTS LIST con’t
79 80
MX135
