McLean T43 - Principles of Operation; Maintenance Guidelines

10-1008-145 Rev. 10 Page 6
T43 Series Components List
Part Number (115 Volt)
Part Description 6000 BTU 8000 BTU 10000 BTU
Capacitor, Compressor, Start 10-1032-05 10-1032-08 10-1032-32
Capacitor, Compressor, Run S-6173 52-6032-01 52-6032-06
Capacitor, Impeller, Condenser 52-6084-01 52-6084-01 52-6031-03
Capacitor, Impeller, Evaporator 52-6084-01 52-6084-01 52-6084-01
Coil, Condenser 45-6051-00 45-6051-00 45-6051-00
Coil, Evaporator 43-6025-00 45-6050-00 45-6050-00
Compressor, RKA 10-1016-86 10-1016-85 10-1016-88
Filter, Air, Reusable 10-1000-96 10-1000-96 10-1000-96
Filter/Dryer 52-6028-00 52-6028-00 52-6028-00
Freeze Stat 10-1033-29 10-1033-29 10-1033-29
Head Pressure Control Switch 52-6104-26 52-6104-26 52-6104-26
Impeller, Condenser 10-1091-123 10-1091-123 10-1091-89
Impeller, Evaporator 10-1091-123 10-1091-123 10-1091-123
Relay, Compressor Start 10-1042-20 10-1042-07 10-1042-17
Service Cord 52-6035-143 52-6035-143 52-6035-85
Thermal Expansion Valve 99-0540-39 (cap tube) 10-1040-37 10-1040-38
Thermal Overload, Compressor TTC=8300MRAL19 OR
TI=MRA4761-114
TTC=8300MRAL22
OR TI=MRA4760-114
Internal
Thermostat, SPST, 55-100F 10-1061-16 10-1061-16 10-1061-16
Part Number (230 Volt)
Part Description 6000 BTU 8000 BTU 10000 BTU
Capacitor, Compressor, Start 10-1032-14 10-1032-08 10-1032-08
Capacitor, Compressor, Run S-6173 S-6173 52-6032-01
Capacitor, Impeller, Condenser 52-6084-02 52-6084-02 52-6084-05
Capacitor, Impeller, Evaporator 52-6084-02 52-6084-02 52-6084-02
Coil, Condenser 45-6051-00 45-6051-00 45-6051-00
Coil, Evaporator 43-6025-00 45-6050-00 45-6050-00
Compressor, RKA 10-1026-109 10-1026-108 10-1026-107
Filter, Air, Reusable 10-1000-96 10-1000-96 10-1000-96
Filter/Dryer 52-6028-00 52-6028-00 52-6028-00
Freeze Stat 10-1033-29 10-1033-29 10-1033-29
Head Pressure Control Switch 52-6104-26 52-6104-26 52-6104-26
Impeller, Condenser 10-1091-124 10-1091-124 10-1091-90
Impeller, Evaporator 10-1091-124 10-1091-124 10-1091-124
Relay, Compressor Start 10-1042-21 10-1042-08 10-1042-17
Service Cord 52-6035-141 52-6035-141 52-6035-141
Thermal Expansion Valve 99-0540-39 (cap tube) 10-1040-37 10-1040-38
Thermal Overload, Compressor TTC=8300MRAL20 OR
TI=MRA4765-114
TTC=8300MRAL23
OR TI=MRA1706-114
TTC=8300MRAL30
OR TI=MRA4764-114
Thermostat, SPST, 55-100F 10-1061-16 10-1061-16 10-1061-16
