Page | 4
3. ASSEMBLY
3.1: Ensure the Foam Pad to the bottom of the cell pack.
3.2 : Ensure the replacement Sealing Gasket is fitted to the replacement LED cap
assembly. Note: Ensure the gasket is seated correctly or product may fail the leak test.
3.3: Ensure the PCB assembly is seated correctly.
