16 IMM AGS-2
Table 6, Spring Vibration Isolators, Aluminum Fin, AGS-CS/H
Mounting Location
AGS
Model
M1 M2 M3 M4 M5 M6 Kit Number
CP2-28 CP2-28 CP2-28 CP2-28 CP2-27 CP2-27
120
GREEN GREEN GREEN GREEN ORANGE ORANGE
330904101
CP2-31 CP2-31 CP2-31 CP2-31 CP2-28 CP2-28
125
GRAY GRAY GRAY GRAY GREEN GREEN
330904102
CP2-28 CP2-28 CP2-28 CP2-28 CP2-27 CP2-27
130
GREEN GREEN GREEN GREEN ORANGE ORANGE
330904101
CP2-31 CP2-31 CP2-31 CP2-31 CP2-28 CP2-28
135
GRAY GRAY GRAY GRAY GREEN GREEN
330904102
CP2-28 CP2-28 CP2-28 CP2-28 CP2-27 CP2-27
140
GREEN GREEN GREEN GREEN ORANGE ORANGE
330904101
CP2-31 CP2-31 CP2-31 CP2-31 CP2-28 CP2-28
145
GRAY GRAY GRAY GRAY GREEN GREEN
330904102
CP2-28 CP2-28 CP2-28 CP2-28 CP2-28 CP2-28
160
GREEN GREEN GREEN GREEN GREEN GREEN
330904103
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
165
GRAY GRAY GRAY GRAY GRAY GRAY
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
170
GRAY GRAY GRAY GRAY GRAY GRAY
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
175
GRAY GRAY GRAY GRAY GRAY GRAY
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
180
GRAY GRAY GRAY GRAY GRAY GRAY
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
190
GRAY GRAY GRAY GRAY GRAY GRAY
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
195
GRAY GRAY GRAY GRAY GRAY GRAY
CP2-31 CP2-31 CP2-31 CP2-31 CP2-31 CP2-31
210
GRAY GRAY GRAY GRAY GRAY GRAY
330904104
Table 7, Neoprene-in-Shear Isolators, Aluminum Fin, AGS-CS/H
Mounting Location (See Footprint Drawings, page 13)
AGS
Model
M1 M2 M3 M4 M5 M6 Kit Number
120
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, BLACK RP-4, BLACK 330904111
125
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED 330904112
130
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, BLACK RP-4, BLACK 330904111
135
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED 330904112
140
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, BLACK RP-4, BLACK 330904111
145
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
160
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
165
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
170
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
175
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
180
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
190
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
195
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
210
RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED RP-4, RED
330904112
