McQuay AGS 120CS/H User Manual

IMM AGS-2 27
Table 18, Physical Data, AGS 190C – AGS 210C
AGS 190C AGS 210C
DATA
Ckt 1 Ckt 2 Ckt 1 Ckt 2
BASIC DATA
Unit Cap. @ 44°F LWT, 95°F Ambient
Temperature kW, (tons)
185.6 (653) 201.2 (707)
Unit Operating Charge lbs (kg) 172 (78) 172 (78) 201 (91) 201 (91)
Cabinet Dimensions
L x W x H, in. (mm)
225 x 89 x 101
5715 x 2261 x 2565
263 x 89 x 101
6680 x 2261 x 2565
Unit Operating Weight, lbs. (kg) 11277 (5120) 11928 (5415)
Unit Shipping Weight, lbs (kg) 10552 (4791) 11011 (4999)
Economizer Yes Yes
COMPRESSORS, SCREW, SEMI-HERMETIC
Nominal Capacity, tons (kW) 95 (334) 95 (334) 95 (334) 95 (334)
CONDENSERS, HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLER
Pumpdown Capacity, lbs (kg) 399 (181) 399 (181) 438 (199) 438 (199)
CONDENSER FANS, DIRECT DRIVE PROPELLER TYPE
No. of Fans -- 30 in. Fan Dia., 10 12
No. of Motors -- hp (kW) 10 2 (1.5) 12 2.5 (1.9)
Fan & Motor RPM, 60Hz 1140 1140
60 Hz Fan Tip Speed, fpm (m/s) 8950 (4224) 8950 (4224)
60 Hz Total Unit Airflow, cfm (l/s) 108630 (51280) 130360 (61530)
EVAPORATOR, DIRECT EXPANSION SHELL AND TUBE
Shell Dia.-Tube Length
in.(mm) - in. (mm)
19.4 x 105.1
(493 x 2670)
19.4 x 105.1
(493 x 2670)
Evaporator R-134a Charge lbs (kg) 3.63 (1.6) 3.63 (1.6) 3.63 (1.6) 3.63 (1.6)
Water Volume, gallons (liters) 106 (401) 104 (392)
Max. Water Pressure, psi (kPa) 152 (1048) 152 (1048)
Max. Refrigerant Press., psi (kPa) 352 (2427) 352 (2427)
Physical Data, High Efficiency
Table 19, Physical Data, AGS 125C – AGS 145C
AGS MODEL NUMBER
125C 135C 145C
DATA
Ckt 1 Ckt 2 Ckt 1 Ckt 2 Ckt 1 Ckt 2
BASIC DATA
Unit Cap. @ 44°F LWT, 95°F Ambient
Temperature kW, (tons)
121.6 (428) 130.9 (460) 143.0 (503)
Unit Operating Charge lbs (kg) 159 (72) 159 (72) 159 (72) 159 (72) 159 (72) 159 (72)
Cabinet Dimensions
L x W x H, in. (mm)
225 x 89 x 101
5715 x 2261 x 2565
225 x 89 x 101
5715 x 2261 x 2565
225 x 89 x 101
5715 x 2261 x 2565
Unit Operating Weight, lbs. (kg) 10930 (4962) 10930 (4962) 10485 (4760)
Unit Shipping Weight, lbs (kg) 10205 (4633) 10205 (4633) 9942 (4514)
Economizer No No No
COMPRESSORS, SCREW, SEMI-HERMETIC
Nominal Capacity, tons (kW) 60 (211) 60 (211) 60 (211) 70 (246) 70 (246) 70 (246)
CONDENSERS, HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLER
Pumpdown Capacity, lbs (kg) 399 (181) 399 (181) 399 (181) 399 (181) 399 (181) 399 (181)
CONDENSER FANS, DIRECT DRIVE PROPELLER TYPE
No. of Fans – 30 in. Fan Dia., 10, 30 (762) 10, 30 (762) 10, 30 (762)
No. of Motors -- hp (kW) 10 2 (1.5) 10 2 (1.5) 10 2 (1.5)
Fan & Motor RPM, 60Hz 1140 1140 1140
60 Hz Fan Tip Speed, fpm (m/s) 8950 (4224) 8950 (4224) 8950 (4224)
60 Hz Total Unit Airflow, cfm (l/s) 108630 (51280) 108630 (51280) 108630 (51280)
EVAPORATOR, DIRECT EXPANSION SHELL AND TUBE
Shell Dia.-Tube Length
in.(mm) - in. (mm)
19.4 x 82.4
(493 x 2093)
19.4 x 82.4
(493 x 2093)
19.4 x 105.1
(493 x 2670)
Evaporator R-134a Charge lbs (kg) 2.53 (1.1) 2.53 (1.1) 2.53 (1.1) 2.53 (1.1) 2.44 (1.1) 2.44 (1.1)
Water Volume, gallons (liters) 83 (314) 83 (314) 62 (236)
Max. Water Pressure, psi (kPa) 152 (1048) 152 (1048) 152 (1048)
Max. Refrigerant Press., psi (kPa) 352 (2427) 352 (2427) 352 (2427)
