Unit Status will display one of the following:
Auto Off:Ice Mode Timer Off:All Cir Disabled
Off:Unit Alarm Off:Keypad Disable Off:Remote Switch
Off:BAS Disable Off:Unit Switch Off:Test Mode
Auto:Wait for load Auto:OAT Lockout Auto:Evap Recirc
Auto:Wait for flow Auto:Pumpdown
Unit mode can show ‘Cool Mode’, ‘Ice Mode’, or ‘Test Mode’.
Pump states include Off, Start, and Run.
VIEW UNIT STATUS (2)
Softload Limit=XXX.X
Demand Limit= XXX.X
Network Limit= XXX.X
Values are in percent.
VIEW UNIT STATUS (3)
Unit Capacity=XXX.X%
Ice Delay= XXh XXm
Unit capacity is based on slide valve(s) position.
Ice delay will be visible only when unit mode is ICE.
VIEW UNIT STATUS (4)
CP1 D.O. 111111111
123456789012345678
XXXXXXXXXXXXXXXXXX
The digital output (D.O.) above and input (D.I.) below, status will show either a “0” or a “1”
designating off and on states.
VIEW UNIT STATUS (5)
CP1 D.I. 111111111
123456789012345678
XXXXXXXXXXXXXXXXXX
VIEW UNIT STATUS (6)
CP1 Analog Outputs
#1=000.0% #2=000.0%
#3=000.0% #4=000.0%
VIEW UNIT STATUS (7)
EXB1 {Status}
D.I. 1234 D.O. 1234
XXXX XXXX
To Next Page
