OM AGSD-1 67
Stage Dn Err=XXX
VIEW FANS (2)
Target Sat T=XXX.XF
VFD Speed= XXX.X%
VFD Target= XXX.XF
This screen appears when the VFD is enabled.
Screen Definitions – ALARM
ALARM LOG: XX
{Alarm Description}
hh:mm mm/dd/yy
{Parameters}
Alarm Description will indicate which alarm occurred. If the alarm is a circuit alarm, then
the circuit for which the alarm occurred will also be indicated.
Parameters at the time of the alarm are shown on the bottom line of the screen one at a time.
They are listed below. They are scrolled through by pressing the edit key and using the up
and down arrows to scroll through the list. Parameters include:
Unit State Evap LWT Evap EWT
OAT Circuit State Evaporator Pressure
Condenser Pressure Oil Pressure Suction Temperature
Discharge Temperature Discharge Superheat EXV Position
EXV State Slide Position Fans On
EVENT LOG: XX
{Event Description}
hh:mm mm/dd/yy
*** ALARM ***
hh:mm mm/dd
{Alarm Description}
This screen shows the current alarm, if there is one.
