Screen Definitions – SET SETPOINTS
NOTE: All setpoint settings are made in CP1. Additional information on controller inputs
and outputs, as well as setpoint defaults and ranges can be found beginning on page
17.
SET UNIT SPs (1)
Enable=On
Mode= COOL
Source = SWITCHES
SET UNIT SPs (2)
Available Modes
= COOL
Select w/Unit Off
The bottom line is a reminder that the unit must be shut off to change modes.
SET UNIT SPs (3)
Cool LWT = XX.XF
Ice LWT = XX.XF
StartDelta=XX.XF
SET UNIT SPs (4)
StopDelta= X.XF
Stg Up Delta= X.XF
Stg Down Delta=X.XF
SET UNIT SPs (5)
Max Pulldn=X.XF/min
EvapRecTimer=XXX sec
Evap Pump= #1 Only
SET UNIT SPs (6)
Reset Type= none
Max Reset = XX.XF
StrtResetDT= XX.X
SET UNIT SPs (7)
Soft Load= Off
Begin Capacity= XXX%
SoftLoadRamp= XXmin
SET UNIT SPs (8)
Demand limit= Off
Low Amb Lock= XX.XF
Num Circuits – X
Number of circuits determines whether circuit #3 will be visible.
To Next Page
