McQuay AGS 225D User Manual

OM AGSD-1 71
SET COMP#N SPs (4)
Slide Pos= XXX.X%
Slide Pos Offset
Min= XX% Max= XX%
SET COMP#N SPs (5)
Pressure Offset(psi)
Evap Cond Oil
XX.X XX.X XX.X
SET COMP#N SPs (6)
Temp Offset(
o
F)
Suction Discharge
X.X X.X
Fan Setpoints
In the following SET CIRN FAN SPs screens, the N field indicates which circuit is being
viewed.
SET CIRN FAN SPs (1)
Number of fans = X
Fan VFD = ON
SET CIRN FAN SPs (2)
Stg On Deadband(F)
1 2 3 4 5 6
XX XX XX XX XX XX
SET CIRN FAN SPs (3)
Stg Off Deadband(F)
2 3 4 5 6
XX XX XX XX XX
SET CIRN FAN SPs (4)
VFD Min speed= XXX%
VFD Max speed= XXX%
SET CIRN FAN SPs (5)
Cond Sat Temp Target
Max= XXX.X F
Min= XXX.X F
