72
OM
AGSD-1
SET FAN SPs (6)
# Fans On At Startup
>75
F >90
F >105
F
X X X
Alarm Setpoints
SET ALARM LIMITS (1)
Low Evap Pressure
Hold=XXXpsi
Unload=XXXpsi
SET ALARM LIMITS (2)
LowOilDelay= XXX sec
HighOilDpDel=XXX sec
SET ALARM LIMITS (3)
High Disc Temp=XXX
F
HighLift Delay=XXsec
SET ALARM LIMITS (4)
Evap Freeze= XX.X
F
Evap Flow Proof=XXXs
LowOATStartTmr=XXsec
Screen Definitions – TEST
TEST UNIT (1)
Alarm Out=Off
Evap Pump 1= Off
Evap Pump 2= Off
TEST UNIT (2)
Comp 1 Enabled=Off
Comp 2 Enabled=Off
Comp 3 Enabled=Off
TEST CIRCUIT (1)
Slide
Load = Off
Unload = Off
71
73
Table of Contents
Default Chapter
2
Table of Contents
2
Controller Features
4
General Description
5
Control Panel Layout
5
Definitions
6
Component Description
9
Hardware Structure
9
System Architecture
10
Sequence of Operation
11
Controller Operation
17
CP1 Inputs/Outputs
17
Analog Inputs
17
Analog Outputs
17
Expansion I/O Controller 1
18
Expansion I/O Controller 4
19
Expansion I/O Controller 3
19
Controller CP2
20
Expansion I/O Controller 5
21
Expansion I/O Controller 8
22
Setpoints
22
Controller Functions
26
Parameter Definitions
26
Unit Enable
26
Unit Mode Selection
28
Unit States
29
Ice Mode Start Delay
30
Evaporator Pump Control
30
Leaving Water Temperature (LWT) Reset
31
Unit Capacity Overrides
33
Building Automation System Interface
34
Circuit Functions
39
Calculations
39
Compressor Control
40
Condenser Fan Control
45
EXV Control
47
Economizer Control
50
Alarms and Events
51
Unit Stop Alarms
51
Unit Events
52
Circuit Stop Alarms
52
Circuit Events
56
Alarm Logging
57
Event Logging
57
Using the Controller
58
Security
60
Editing Setpoints
61
Clearing Alarms
61
Unit Controller (CP1) Screens
61
Editing Review
73
Start-Up and Shutdown
74
Temporary Shutdown
74
Extended (Seasonal) Shutdown
75
Field Wiring Diagram
78
